[React Native] React Navigation 설치 및 사용법
Deprecated

[React Native] React Navigation 설치 및 사용법

2020. 2. 7. 23:29

Copyright © 2020 Facebook Inc.

[React Native] React Navigation 설치 및 사용법

(React Navigation 버전 : 5~, 글쓴날 : 2020.02.07)




* React Navigation V5 이전의 createAppContainer가 deprecated되었습니다... ㅠ.ㅠ






1. React Navigation 설치


1) React Navigation 패키지 설치

npm install @react-navigation/native



* npm 및 패키지 설치에 관해 궁금하시다면 ☞ [Node.js] npm 소개와 설치 및 사용법


2) 의존 패키지 설치

npm install react-native-reanimated react-native-gesture-handler react-native-screens react-native-safe-area-context @react-native-community/masked-view


3) iOS 설정

cd ios && pod install (이럴때는 갓 iOS입니다..)


4) Android 설정

(1) android/app/build.gradle의 dependencies 구간에 아래의 2줄 추가해주세요.

implementation 'androidx.appcompat:appcompat:1.1.0-rc01’

implementation 'androidx.swiperefreshlayout:swiperefreshlayout:1.1.0-alpha02’


(2) MainActivity.java에 아래의 react-native-gesture-handler추가 코드를 삽입해주세요.

package com.reactnavigation.example;

import com.facebook.react.ReactActivity;
import com.facebook.react.ReactActivityDelegate;
import com.facebook.react.ReactRootView;
import com.swmansion.gesturehandler.react.RNGestureHandlerEnabledRootView;

public class MainActivity extends ReactActivity {

  @Override
  protected String getMainComponentName() {
    return "Example";
  }

  @Override
  protected ReactActivityDelegate createReactActivityDelegate() {
    return new ReactActivityDelegate(this, getMainComponentName()) {
      @Override
      protected ReactRootView createRootView() {
        return new RNGestureHandlerEnabledRootView(MainActivity.this);
      }
    };
  }
}


5) import 'react-native-gesture-handler';를 사용할 index.js나 app.js 맨 위에 작성

하지만 작성하지 않았는데도 이상 없이 잘 돌아감... (차후 확인할 것)


6) createStackNavigator를 사용하려면 추가로 패키지 설치

npm install @react-navigation/stack


* 기본 코드 구조 예제

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
import * as React from 'react';
import { View, Text } from 'react-native';
import { NavigationContainer } from '@react-navigation/native';
import { createStackNavigator } from '@react-navigation/stack';

function HomeScreen() {
  return (
    <View style={{ flex: 1, alignItems: 'center', justifyContent: 'center' }}>
      <Text>Home Screen</Text>
    </View>
  );
}

const Stack = createStackNavigator();

function App() {
  return (
    <NavigationContainer>
      <Stack.Navigator>
        <Stack.Screen name="Home" component={HomeScreen} />
      </Stack.Navigator>
    </NavigationContainer>
  );
}

export default App;













2. React Navigation 사용법


1) Screen 생성 및 스택화

import { NavigationContainer } from '@react-navigation/native';

import { createStackNavigator } from '@react-navigation/stack';



선언 후



첫 스크린이 될 HomeScreen을 생성해주세요.

1
2
3
4
5
6
7
function HomeScreen() {
  return (
    <View style={{ flex: 1, alignItems: 'center', justifyContent: 'center' }}>
      <Text>Home Screen</Text>
    </View>
  );
}



그 다음



createStackNavigator함수를 호출하여 사용하실 변수에 객체를 할당해주세요. (변수명 자유)

ex) const Stack = createStackNavigator();



그 후



NavigationContainer컴포넌트 안에 위에서 할당받은 객체(const Stack)의 Navigator 컴포넌트를 이용하여 각 Screen을 스택화해주세요. (4, 5, 6 라인)

1
2
3
4
5
6
7
8
9
function App() {
  return (
    <NavigationContainer>
      <Stack.Navigator>
        <Stack.Screen name="Home" component={HomeScreen} />
      </Stack.Navigator>
    </NavigationContainer>
  );
}

끝으로 Screen을 추가할때마다 위의 작업을 반복하면 됩니다!



- prop 설명 -

(1) Stack.Navigator의 initialRouteName prop : Screen이 여러 개 일시 홈 스크린을 지정합니다.

ex) <Stack.Navigator initialRouteName="Home">



(2) Stack.Screen의 options prop : 각 Screen의 title등을 지정할 수 있습니다.

ex) <Stack.Screen name="Home" component={HomeScreen} options={{ title: 'test' }} />



(3) Stack.Screen의 screenOptions prop : 모든 Screen에 동일한 옵션을 지정할 수 있습니다.

ex) <Stack.Screen name="Home" component={HomeScreen} screenOptions={{ title: 'test' }} />


2) Screen간의 이동(navigation)



* Screen navigation 예제

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
import * as React from 'react';
import { Button, View, Text } from 'react-native';
import { NavigationContainer } from '@react-navigation/native';
import { createStackNavigator } from '@react-navigation/stack';

function HomeScreen({ navigation }) {
  return (
    <View style={{ flex: 1, alignItems: 'center', justifyContent: 'center' }}>
      <Text>Home Screen</Text>
      <Button
        title="Go to Details"
        onPress={() => navigation.navigate('Details')}
      />
    </View>
  );
}

function DetailsScreen({ navigation }) {
  return (
    <View style={{ flex: 1, alignItems: 'center', justifyContent: 'center' }}>
      <Text>Details Screen</Text>
      <Button
        title="Go to Details... again"
        onPress={() => navigation.push('Details')}
      />
      <Button title="Go to Home" onPress={() => navigation.navigate('Home')} />
      <Button title="Go back" onPress={() => navigation.goBack()} />
      <Button
        title="Go back to first screen in stack"
        onPress={() => navigation.popToTop()}
      />
    </View>
  );
}

const Stack = createStackNavigator();

function App() {
  return (
    <NavigationContainer>
      <Stack.Navigator initialRouteName="Home">
        <Stack.Screen name="Home" component={HomeScreen} />
        <Stack.Screen name="Details" component={DetailsScreen} />
      </Stack.Navigator>
    </NavigationContainer>
  );
}

export default App;



- navigation설명 -

(1) navigation.navigate(‘example screen’) : example screen으로 이동합니다.

단, 현재 example screen일 시 스택을 쌓을 수 없습니다. (같은 곳으로 이동 불가능)



(2) navigation.push('example screen') : example screen으로 이동합니다.

단, 현재 example screen이어도 중복으로 계속 스택을 쌓을 수 있습니다. (같은 곳으로 이동 가능)



(3) navigation.goBack() : 이전 Screen으로 이동합니다.

헤더바에 뒤로가기 버튼이 생기지만(첫 화면제외) 프로그래밍적으로 뒤로갈 때 사용합니다.

안드로이드 하단의 뒤로가기 버튼과 기능상 동일합니다.



(4) navigation.popToTop() : 첫 Screen으로 이동합니다. (스택에 쌓여있는 Screen이 모두 제거됩니다!)









여기까지 React Navigation의 설치 및 사용법이었습니다.

제가 위에서 설명해드린 사용방법들은 React Navigation의 기본적인 사용법입니다.

이 밖에도 수많은 기능들이 존재하므로 더 많은 기능과 사용법을 알고 싶으시다면...



* React Navigation 공식 홈페이지 : React Navigation 공식 홈페이지



React Navigation · Routing and navigation for your React Native apps

Routing and navigation for your React Native apps

reactnavigation.org

위의 React Navigation 공식 홈페이지를 참조하시면 되겠습니다.

감사합니다!
